Location:Home > 產品中心 > Coordinate series lock screw machine series
SK-805G Air Suction Lock Screw Machine (Cabinet Type) Loading Zoom, please wait
SK-805G Air Suction Lock Screw Machine (Cabinet Type)
產品簡介：示教編程，簡單操作 高效打螺絲,1.2s~1.8s/pcs（螺絲長度、產品大小有差異） 雙工位交替作業，取放產品螺絲鎖附同步進行，更高效 Teaching programming, simple operation High-efficiency screw driving, 1.2s~1.8s/pcs (difference in screw length, product size) Double alternate operation, take and put the product screw lock synchronous, more efficient
咨詢熱線：
產品詳情

SK-805G Air Suction Lock Screw Machine (Cabinet Type)

▲(四)參數 Specification


型號Model
SK-805G
外觀尺寸 Dimension
根據客戶要求定制：Customize according to the customer request
適用最大產品尺寸 Max.product size
200mm*300mm
驅動模式 Driving mode
閉環電機+同步帶 Closed-loop motor+synchronous beit
控制模式 Control mode
觸摸屏/手柄; Touch screen /Handle
適用螺絲規格 Applicable screw size
M1~M4
可移動范圍 Moving range
X軸； X Axis
X=500mm
Y1/Y2軸； Y1、Y2 Axis
Y1=300mm,Y2=300mm
Z軸； Z Axis
Z=100mm
運動最高速度Max.sped
X/Y1/Y2軸； X、Y1、Y2 Axis
1000mm/sec
Z軸； Z Axis
800mm/sec
重復精度Repeatedaccuracy
X/Y1/Y2軸； X、Y1、Y2 Axis
±0.05mm
Z軸； Z Axis
±0.05mm
記憶容量 Memory
999個文件； 999files
電批 Screwdriver
智能伺服電批；Intelligent servo electric batch
螺絲取料方式 Screw feeding
吸氣式； Adsorption
工作臺最大載重 Max.laod
15kg
報警提示功能 Alarm system
漏鎖、浮牙、滑牙報警；Alarm for missing lock, floating teeth and sliding teeth
編程方法 Programming
牽引示教編程/手持編程器； Traction teaching programming /Handheld programme
凈重 Net weight
100kg
功率 Power
500W
輸入電壓 Input voltage
220V AC/50Hz(110V AC/60Hz)
工作氣壓 Working air pressure
0.4~0.6MPa
工作環境Work environment
溫度：-20℃~40℃，濕度：20%~95%；Temperature: - 20 ℃ ~ 40 ℃, Humidity: 20% ~ 95%
